Gasoline generator 10 kW FOGO FV 15000 TE

FOGO FV 15000 TE - three-phase gasoline generator with Vanguard 3854 engine. Starting is done using an electric starter or manually. The nominal power of the generator on 1 phase is 6 kW, on 3 phases 10 kW. The nominal current on 1 phase is 26.1 A, on 3 phases 18.1 A. The generator has a built-in voltage stabilization system (AVR) and a thermal relay that turns off the engine when the critical operating temperature is reached. Additionally, the technology of protecting the engine from operating without lubrication with its emergency shutdown has been implemented.

The generator is highly economical and has increased efficiency. Fuel consumption at 75% load is 4.9 l/h. Equipped with a high-quality alternator from the manufacturer Sincro (Italy) with protection class IP 54.

Designed to restore electricity supply in case of power grid failures or lack of other power sources, when the stationary network is unavailable or damaged.

Features:

• automatic engine stop at low oil level
• digital voltage regulation AVR +/- 2%
• digital AVR system, which guarantees operation without overloads and does not allow voltage surges THD ≤ 6%
• load protection
• thermal relay
• oil pressure sensor
• one protected socket for 230V 16A
• one protected socket for 380V 32A
• generator protection class IP 23
• generator insulation class H
• generator starting current 400%
• reinforced frame profile 38 mm
• silencer with exhaust hose connection
• battery
• hour meter
